Photochemical Etching Machine For Steel Engraved Flexible Dies

Photochemical Etching Machine For Steel Engraved Flexible Dies

Description
Model NO.: DB5060 Etching Type: One-Side Spray
Precision: Precision Condition: New
Power: 7.5kw/380V Working Size: 500*600mm
Heat System: Titanium,3kw Cool System: Titanium Pipe
Motor Power: 4kw/380V Transport Package: Wooden Case
Specification: CE Trademark: Golden Eagle
Origin: Beijing, China HS Code: 84862090
Supply Ability: 25 Sets/Month After-sales Service: 1year. After 1year,Once Some Components Are Broke
Warranty: 1year. After 1year,Once Some Components Are Broke Type: Photochemical Etching Machine
Object: Metal Usage: Corrosion & Hollowed-out
Certification: CE


Steel Engraved Flexible Dies Etching Machine

dB5060 cutting die etching machine

dB5060 Flexible Magnetic Dies Etching Machine

DB5060 Photo Etching Machine for flexible dies

DB5060 Steel Flexible Dies Etching Machine
Product Parameters



Power: 7.5KW/380V
Working Size: 500*600mm
Etching type: Vertical spraying
Working Temp: 40~55 degrees
Heat System: Titanium, 3KW
Cool System: Titanium Pipe
Motor power: 4KW/380V
Machine Size: 1950*1350*1550mm
Weight About; 550kgs

Product Description

Control system: Temperature, Speed, Pressure, Network Filter


Making Process: Dry film photoresist & ink --- expose --- developer --- etching -- stripper --- cleaning --- drying --- CNC engraving ---- nickel & chrome plating --- finished

Introduction:
1. Flexible Dies Etching machine is a photoengraving machines for steel or high-carbon steel plate mold pretreating etching to advance following engraving processing.
2. After etching, the cutting knife-edge and knife depth is etched out.
3. Then the following CNC engraving Knife sharpening works is easy and fast.
4. It can save lots of unnecessary cost compare to use CNC engraving to working completely.

Detailed Photos



Steel Engraved Flexible Dies Etching Machine/Cutting Dies Etching Machine Steel Engraved Flexible Dies Etching Machine/Cutting Dies Etching Machine Steel Engraved Flexible Dies Etching Machine/Cutting Dies Etching Machine Steel Engraved Flexible Dies Etching Machine/Cutting Dies Etching Machine Steel Engraved Flexible Dies Etching Machine/Cutting Dies Etching Machine Steel Engraved Flexible Dies Etching Machine/Cutting Dies Etching Machine
Packaging & Shipping



Steel Engraved Flexible Dies Etching Machine/Cutting Dies Etching Machine Steel Engraved Flexible Dies Etching Machine/Cutting Dies Etching Machine
