650mm Working Width PCB-B650 PCB Brushing Machine/PCB Equipment Model NO. Can Be Order

Certification
China Beijing Golden Eagle Technology Development Co., Ltd. certification
I'm Online Chat Now

650mm Working Width PCB-B650 PCB Brushing Machine/PCB Equipment Model NO. Can Be Order

650mm Working Width PCB-B650 PCB Brushing Machine/PCB Equipment Model NO. Can Be Order

Description
Model NO.: PCB-B650 Brush Size: 500# 800#
Plate Thickness: 0.2~3.2mm Conveyor Speed: 0.5~6m/MIM
Machine Size: 7500*1700*1840mm Weight: 2500kgs
Package: Wooden Packaging Lead Time: 25days
Custom: Customized Transport Package: Standard Export Wooden Case
Specification: CE Trademark: GOLDEN EAGLE
Origin: China HS Code: 84862090
Supply Ability: 20 Sets/Month After-sales Service: 1year. After 1year,Once Some Components Are Broke
Warranty: 1year. After 1year,Once Some Components Are Broke Certification: CE
Condition: New Application: Circuit Board Or Metal Surface Treatment
Working Width: 650mm (Can Be Order)

Pcb Brushing Machine/Pcb Equipment


Product Parameters
Machine Name:Double Side Brushing Machine
Power 18KW/380V/50HZ
Working width 650mm
Working height 925mm  ( +/-50mm)
Brush Size 500# 800#  ( 2units per model)
Brush type Double Brushing & Swing
Brush motor 1.5KW*4 sets
Rinse Pump 1.1KW*3sets,3KW*1set
Swing motor 200W * 1set
Cold/hot blower 950W /950W
Machine Size 6700*1700*1840mm



Product Description

Process

Enter- - Acid rinse- - Water rinse- - Double brushing- - Pressure washing- - Cold dry- - Hot dry- - Out

Introduction

1. This brushing machine can remove the oxide layer and dust of PCB with high speed and efficacy.
2. Stable and reliable transmission system, reasonable swing durable institutions, as well as very convenient brush roller replacement of the mechanical structure, which greatly improved the production efficiency and product quality.
3. Well-designed water systems, significantly save the water consumption.

Detailed Photos
PCB-B650 PCB Brushing Machine/PCB Equipment PCB-B650 PCB Brushing Machine/PCB Equipment PCB-B650 PCB Brushing Machine/PCB Equipment PCB-B650 PCB Brushing Machine/PCB Equipment



PCB-B650 PCB Brushing Machine/PCB Equipment

FAQ

1.Q:Are you trading company or a factory ?

   A: We are manufactory and We have import and export License .

2.Q:Where is your factory ?How Can I visit there?

   A: Our factory is located in Beijing, the capital of China,Warmly welcome to visit us.

3.Q:How can I get some samples ?

   A: we are honores to offer you samples,please contact us anytime !

4.Q: How does your factory do regarding quality control ?

   A: Quality is priority .Golden Eagle people always attach great importance to quality controlling from A to Z.

5.Q:Why us ?

   A: 1.  20 years machine manufacture experiences !

       2.  More than 10 years good credit supplier on Made-in-China

       3.  satisfaction or we'll refund or rerun-your choice

       4.  Etching technology can be provided for free to our customer by our well-trained and professional  engineers and staffs.


After Sales Service

1.Customized design is available.

2.Master operator training program for free.

3.Reasonable and  negotiable  price,short lead time.


Packaging & Shipping

PCB-B650 PCB Brushing Machine/PCB Equipment

Company Profile

Beijing Golden Eagle Electronic Equipments Co.,Ltd located Beijing, the capital of China. We manufacturer of printed circuit board (PCB) manufacturing equipment & machinery including chemical etchers, strippers, cleaners & dryers. PCB Etching Equipment and Wet processing equipment and Chemical Milling machine and Metal etchers.

We can supply whole processing equipments and support with whole processes technique training. maily used In Metal etching,PCB etching ,FPC etching,Precision parts etching,Cutting Dies & Hot stamping dies etching,nameplate & medal etching, Press plate etching,Decoration plate etching and so on. material can be stainless steel,copper,brass,aluminum,zinc,magnesium and so on.

In the past 20 years, we sold variety of etching machines to Australia,ARGENTINA,Armenian,Belarus,Bulgaria,Belgium, Canada,Colombia,Czech Republic,Egypt,FRANCE,INDIA,IRAN,Kuwait,Lebanon,MEXICO,Malaysia,PORTUGAL,QATAR,Romania,Saudi Arabia,Singapore,Sweden,SPAIN, Sri Lanka,THAILAND,TURKEY,U.A.E.,USA,United Kingdom,and many other countrys.

Our mission is to deliver high-quality, reliable manufacturing solutions that are designed to meet each customer's unique needs.
PCB-B650 PCB Brushing Machine/PCB Equipment
