Product Details:
|
| Model NO.: | GE-JM650 | Etching Type: | Double Spray |
|---|---|---|---|
| Precision: | High Precision | Condition: | New |
| Model: | Ge-Jm650 | Working Width: | 650mm |
| Etching Area: | 650*2000mm | Power: | 11.5kw/380V/50Hz |
| Etched Type: | Double Spraying & Oscillate | Swing System: | Oscillate Nozzles |
| Working Temperature: | 37~45°c | Vertical Pump: | 4kw, 2units |
| Machine Size: | 3550*1500*1450mm | Weight About: | 850kgs |
| Transport Package: | Wooden Case | Specification: | CE |
| Trademark: | Golden Eagle | Origin: | Beijing, China |
| HS Code: | 848620900 | Supply Ability: | 25 Sets/Month |
| After-sales Service: | After 1year,Once Some Components Are Broke | Warranty: | After 1year,Once Some Components Are Broke |
| Type: | Photochemical Etching Machine | Object: | Metal |
| Usage: | Corrosion & Hollowed-out | Certification: | CE |
| Samples: | US$ 500/Piece 1 Piece(Min.Order) | Request Sample |
| Auto Double Side Etching Machine | |
| Power | 16KW/380V/50HZ |
| Working width | 650mm |
| Etching area | Length:2000mm |
| Pump:4KW/set,2sets | |
| Double Spraying & Oscillate Pressure control for every spray pipe | |
| Heater: Titanium pipe,3KW/1groups | |
| Cooling: Titanium pipe,1set | |
| Working Temp:37~55ºC | |
Rinse area | Length: 500mm, 1parts |
| Pump:2.2KW/set,1sets | |
| Double spraying | |
| Machine Size | 4500*1650*1700mm |
| Weight | About 1000kgs |
Process:
Load (500mm) → Etching1,2 (2000mm)→Pressure rinse1(500mm)→Unload (500mm)
